K2 LED Linear High Bay Light


Product Parameters:

  • Wattage: 100W 150W 200W 250W 300W 360W 400W 500W
  • Luminous Efficacy: 152LM/W
  • Lumen Output: 15200lm-76000lm
  • Warranty: 7 years
  • Certification: UL,DLC,CB,CE,SAA,SASO,IP65
See Price

K2 LED Linear High Bay Light

HS-HB-K2 linear LED luminairies deliver a high lumen output to replace legacy HID and 2-, 4- or 6-lamp T5HO fluorescent fixtures in both low bay and high bay applications. The HS-HB-K2 family of linear LED high bay fixtures are available in eight different wattages including 100W, 150W, 200W, 250W, 300W, 360W, 400W and 500W. They’re designed to replace 1300W HID equivalents while achieving up to 75% energy savings. Rugged construction and sophisticated LED technology add unparalleled energy efficiency and reliability for years of maintenance-free operation.

The HS-HB-K2 linear high bay delivers industry-leading performance with an extremely attractive payback advantage. The full body assembly features a value-optimized chassis design and is made of extruded aluminum that provides durable protection and optimal heat dissipation for LEDs, optics and electrical components. The high flux density SMD LEDs produce 152 lm/W system efficacy (lensed). Combined with perfectly matched driving circuit with full featured protections as well as superior thermal management, HS-HB-K2 LED modules offer an extraordinary lumen maintenance greater than 90 percent at 50,000 hours and projected life over 200,000 hours.

K2 LED Linear High Bay Light Product Specifications

K2 LED Linear High Bay Light Product  Specifications

K2 LED Linear High Bay Light Specification

K2 LED Linear High Bay Light Specification

K2 LED Linear High Bay Light Product Parameters

Part Number

HS-HB100W/150W-K2

HS-HB200W/250W-K2

HS-HB300W/360W-K2

HS-HB400W/500W-K2

Wattage

100W/150W

200W/250W

300W/360W

400W/500W

Lumen Output

15200lm/22800lm

30400lm/38000lm

45600lm/54720lm

60800lm/76000lm

LED Quantity

154pcs

308pcs

462pcs

616pcs

Size(MM)

L298*W100*H26.5

L590*W100*H26.5

L885*W100*H26.5

L1180*W100*H26.5

LED Chip

Lumileds/Cree

Luminous Efficacy

152LM/W

CCT

3000K-6500K

CRI

≥80

Beam Angle

60°/90°/120°

IP Rating

IP65





Working Temperature

-30℃ to +55℃

Input Voltage

AC100-277V/347V/480V, 50/60Hz, >0.92

Warranty

7 years

Lifespan

>50,000hrs

Material

Die-casting Aluminum housing+PC lens

Key Features Of K2 LED Linear High Bay Light

•  Separate heat sink for driver and Led chip

•  Three-dimensional diamond light guide technology

•  Beam angle 60° /90° /120° with transparent / frosted PC lens available

•  Endless Connection

• Colorful housing can be customized

Key Features Of K2 LED Linear High Bay Light

K2 LED Linear High Bay Light Intelligent Control

K2 LED Linear High Bay Light Intelligent Control: 0-10V Dimming,Timer Control, Zigbee Control, Occupancy sensor,Daylight sensor,Emergency power supply,DALI Control

K2 LED Linear High Bay Light Intelligent Control

K2 LED Linear High Bay Light Lens And Beam Angle

Milky Lens And Transparent Lens

View angle 60°/90°/120° available

Milky Lens Light did not glare but warm,always in pression

Transparent Lens Transparent Lens transmittance over 92%

K2 LED Linear High Bay Light Lens And Beam Angle

K2 LED Linear High Bay Light IP Rating IP65

Silicon rubber ring sealing process, IP grade reach IP65,

completely prevent dust invasion and heavy rain.

K2 LED Linear High Bay Light IP Rating IP65

K2 LED Linear High Bay Light Multiple Mounting Options

K2 LED Linear High Bay Light Multiple  Mounting Options

K2 LED Linear High Bay Light Applications

Widely used in Factory, Workshop, Warehouse, Logistics Center Exhibition Hall,Gymna-sium, Shipyards, Mining, Gas Station, Supermarket, etc.

K2 LED Linear High Bay Light Applications 1

K2 LED Linear High Bay Light Applications
